E5@C Digital Temperature Controllers User’s Manual (H174)
 E5EC-B (Models with Push-In Plus Terminal Blocks)
*1 Options with 004 and 014 cannot be selected if a relay output or voltage output (for driving SSR) is selected for the
control output.
*2 Options with 008, 010 and 011 cannot be selected if a linear current output is selected for the control output.
The control output cannot be used as a simple transfer output.
(1) (2) (3) (4) (5) (6) (7) Meaning
E
48 × 96 mm
Control output 1 Control output 2
*1 R X Relay output None
*1 Q X Voltage output (for driving SSR) None
*2 C X Linear current output None
22
44
A 100 to 240 VAC
D 24 VAC/DC
B Push-In Plus terminal blocks
M Universal input
Event inputs
Communicat
ions
Remote SP
input
HB alarm
and HS
alarm
Transfer
output
000 --- --- --- --- ---
004 2 RS-485 --- --- ---
008 2 RS-485 --- 1 ---
010 4 --- --- 1 ---
011 6 --- Provided. 1 Provided.
014 4 RS-485 Provided. --- Provided.
-- -
E5EC
- -
(1) (2) (3) (4) (5) (6) (7)
B
Size
Control Outputs 1 and 2
No. of auxiliary outputs
Power supply voltage
Terminal type
Input type
Options
