G-54 Safety Sensors / Components
Dimensions
F3S-TGR-SB-K@C-@@@ with Mounting Brackets
Applicable standards 93/68/EEC
DIN V VDE 0801:1990 and am.A1:1994
EN 50081-2:1993
EN 55022:1998
Model A C E
F3S-TGR-SB@-K2C500 614 mm 500 mm 500 mm
F3S-TGR-SB@-K3C800 914 mm 800 mm 400 mm
F3S-TGR-SB@-K4C900 1,014 mm 900 mm 300 mm
Item Model F39-TGR-SB-CMB@
47.5 37.7
35
13
73 C, E
A
