F3SG-SR/PG
16
Laser Alignment Pointer
* Cannot be mounted on the passive mirror.
Lamp
* When the accessory is used, protect it from cutting oil.
Note: The Lamp does not support Bluetooth
®
communication.
Test Rod *
* The customer needs to prepare a test rod lager than 25-mm dia.
Appearance Specifications Model
The laser alignment pointer is attached on the optical surface of the F3SG-SR/PG to help
coarse adjustment of beams. *
F39-PTG
Appearance Specifications Model
The lamp can be connected to emitter, receiver, or emitter/receiver and turned ON based on
the operation of F3SG-SR/PG.
The lamp can indicate red, orange, and green colors, to which three different states can be
assigned.
IP67 * rated when mated.
F39-SGLP
Diameter Model
14 mm dia. STI-TO14(42800-0240)
25 mm dia. STI-TO24(42800-0260)
