Omron F3SG-SR/PG - Page 26

F3SG-SR/PG
26
List of Models/Response Time/
Current Consumption/Weight
Hand protection (Detection capability: 25-mm dia.)
List of Models and Response Times
Note: 1. The maximum speed of movement of a test rod up to which the detection capability is maintained is 2.0 m/s.
2. The response times of "Optical synchronization" are values when Scan Code is set at Code B. The response times for Code A are 1 ms
shorter than these values.
Model
Number of
beams
Protective
height [mm]
Response time
(Optical synchronization) [ms]
Response time
(Wired
synchronization)
[ms]
ON to
OFF
OFF
(synchronized)
to ON
OFF (not
synchronized)
to ON
ON to
OFF
OFF to
ON
F3SG-4SR0160-25 8 160 8 40 140 10 50
F3SG-4SR0200-25-F 10 200 8 40 140 10 50
F3SG-4SR0240-25 12 240 8 40 140 10 50
F3SG-4SR0280-25-F 14 280 8 40 140 10 50
F3SG-4SR0320-25 16 320 8 40 140 10 50
F3SG-4SR0360-25-F 18 360 8 40 140 10 50
F3SG-4SR0400-25 20 400 8 40 140 10 50
F3SG-4SR0440-25-F 22 440 8 40 140 10 50
F3SG-4SR0480-25 24 480 8 40 140 10 50
F3SG-4SR0520-25-F 26 520 8 40 140 10 50
F3SG-4SR0560-25 28 560 8 40 140 10 50
F3SG-4SR0600-25-F 30 600 8 40 140 10 50
F3SG-4SR0640-25 32 640 8 40 140 10 50
F3SG-4SR0680-25-F 34 680 8 40 140 10 50
F3SG-4SR0720-25 36 720 8 40 140 10 50
F3SG-4SR0760-25-F 38 760 8 40 140 10 50
F3SG-4SR0800-25 40 800 8 40 140 10 50
F3SG-4SR0840-25-F 42 840 13 65 165 17 85
F3SG-4SR0880-25 44 880 13 65 165 17 85
F3SG-4SR0920-25-F 46 920 13 65 165 17 85
F3SG-4SR0960-25 48 960 13 65 165 17 85
F3SG-4SR1000-25-F 50 1000 13 65 165 17 85
F3SG-4SR1040-25 52 1040 13 65 165 17 85
F3SG-4SR1120-25 56 1120 13 65 165 17 85
F3SG-4SR1200-25 60 1200 13 65 165 17 85
F3SG-4SR1280-25 64 1280 13 65 165 17 85
F3SG-4SR1360-25 68 1360 13 65 165 17 85
F3SG-4SR1440-25 72 1440 13 65 165 17 85
F3SG-4SR1520-25 76 1520 13 65 165 17 85
F3SG-4SR1600-25 80 1600 13 65 165 17 85
F3SG-4SR1680-25 84 1680 13 65 165 17 85
F3SG-4SR1760-25 88 1760 13 65 165 17 85
F3SG-4SR1840-25 92 1840 13 65 165 17 85
F3SG-4SR1920-25 96 1920 13 65 165 17 85
F3SG-4SR2080-25 104 2080 13 65 165 17 85
F3SG-4SR2280-25 114 2280 13 65 165 17 85
F3SG-4SR2480-25 124 2480 13 65 165 17 85
