Dimensions
Adjustable Top/Bottom Bracket (F3SG-RA/RE Adapter) (F39-LSGTB-RE, sold separately)
Adjustable Top/Bottom Bracket (MS4800, F3SR Adapter) (F39-LSGTB-MS, sold separately)
4.6
47.7
12
3.2
147.2
9.5
32
39.2
15
20
22.2
Material: High rolled steel (SPHC)
R4.1
R3.3
Material: High rolled steel (SPHC)
4.6
47.7
12
3.2
154
46
18.4
32
23.2
R3.4
R3.4
R3.4
38.1
52.8
