Dimensions
Assembly Dimensions (Intelligent Tap/ Intelligent Tap Bracket)
Bluetooth
®
Communication Unit (F39-SGBT, sold separately)
Assembly Dimensions (Intelligent Tap/Bluetooth
®
Communication Unit/Intelligent Tap Bracket)
Intelligent Tap F39-SGIT-IL3
Intelligent Tap Bracket
F39-LITF1
Material: PBT resin (Body parts)
75
40
39.7
4
111
30.3
47.8
<Mounting on DIN track>
31.9
40.7
19.7
Material: PBT resin (Body parts)
75
40.7
49.1
30
（9.4）
31.9
40
2
111
30.3
47.8
Intelligent Tap Bracket
F39-LITF1
Intelligent Tap
F39-SGIT-IL3
Bluetooth
®
Communication Unit F39-SGBT
