69
F3SJ-E/B
User’s Manual
Chapter3 Dimensions
Wiring/Installation
E
Dimensions of contact mount bracket
16
30
32
2
13.54
7.5
34.5
19
6.5
dia. 9
Material: Stainless
(Unit: mm)
