Appear-
ance
Type Description
Color/
Mono-
chrome
Image Ac-
quisition
T
ime
*1
Model
Digital CMOS Cameras
(Lens required)
20.4 megapixels
(Up to four cam-
eras can be con-
nected to one
Controller. Cam-
era on page 1-5)
Color
42.6 ms
*2
FH-SC21R
Mono-
chrome
FH-SM21R
5 megapixels Color 71.7 ms FH-SC05R
Mono-
chrome
FH-SM05R
5 megapixels Color 38.2 ms FZ-SC5M3
Mono-
chrome
FZ-S5M3
Digital CCD Cameras
(Lens required)
2 megapixels Color 33.3 ms FZ-SC2M
Mono-
chrome
FZ-S2M
0.3 megapixels Color 12.5 ms FZ-SC
Mono-
chrome
FZ-S
High-speed Digital CCD Cam-
eras
(Lens required)
0.3 megapixels Color 4.9 ms FZ-SHC
Mono-
chrome
FZ-SH
Small Digital CCD Cameras
(Lenses for small camera re-
quired)
0.3 megapixels
flat type
Color 12.5 ms FZ-SFC
Mono-
chrome
FZ-SF
0.3 megapixels
pen type
Color 12.5 ms FZ-SPC
Mono-
chrome
FZ-SP
Intelligent Compact Digital
CMOS Cameras
(Camera + Manual Focus Lens
+ High power Lighting)
*5
Narrow view Color 16.7 ms FZ-SQ010F
Standard view Color FZ-SQ050F
Wide View (long-
distance)
Color FZ-SQ100F
Wide View (short-
distance)
Color FZ-SQ100N
*1. The image acquisition time does not include image conversion processing time by the Sensor Controller.
*2. Frame rate in high speed mode when the camera is connected using two camera cables. For other condi-
tions, please refer to 3-2-1
High-speed digital CMOS Camera (FH-S camera series) on page 3-22.
*3. The value in high speed mode. For other information, refer to 3-2-1 High-speed digital CMOS Camera (FH-
S camera series) on page 3-22.
*4.
Up to eight cameras other than 12 megapixels cameras can be connected to a FH-5£££-20, FH-3££
£-20, FH-2£££-20, or FH-1£££-20.
*5.
When the built-in lighting of an FZ-SQ££££ is used, it may not be possible to shorten the processing time
due to restrictions on the light emission time.
1 Confirm the Package
1-6
FH Series Vision System Hardware Setup Manual (Z366-E1)
