Series FH-L Series
Type Lite Controller
Model FH-L550 FH-L550-10
Built-in FAN None
Usage
Environ-
ment
Ambient temperature
range
Operating: 0°C to +55°C
Storage: -25 to +70°C (with no icing or condensation)
Ambient humidity
range
Operating and Storage: 10 to 90% (with no condensation)
Ambient atmosphere No corrosive gases
Vibration tolerance 5 to 8.4 Hz with 3.5 mm amplitude, 8.4 to 150 Hz, acceleration of 9.8
m/s
2
100 min each in X, Y
, and Z directions (10 sweeps of 10 min each = 100
min total)
Shock resistance
Impact force: 150 m/s
2
T
est direction: up and down/front and behind/left and right
Noise im-
munity
Fast Tran-
sient
Burst
• DC power:
Direct infusion: 2 kV
, Pulse rising: 5 ns, Pulse width: 50 ns, Burst con-
tinuation time: 15 ms/0.75 ms, Period: 300 ms, Application time: 1 min.
• I/O line:
Direct infusion: 1 kV, Pulse rising: 5 ns, Pulse width: 50 ns, Burst con-
tinuation time: 15 ms/0.75 ms, Period: 300 ms, Application time: 1 min.
Grounding
Class D grounding (100 Ω or less grounding resistance)
*1
External
Features
Dimensions 200 mm x 80 mm x 130 mm
Weight Approx. 1.5kg Approx. 1.5kg
Degree of protection IEC60529 IP20
Case material PC
*1. Existing the third class grounding
3 Configuration
3-18
FH Series Vision System Hardware Setup Manual (Z366-E1)
