Model FH-SM04 FH-SC04 FH-SM12 FH-SC12
Pixel size 5.5 (μm) x 5.5 (μm) 5.5 (μm) x 5.5 (μm)
Shutter function Electronic shutter:
Shutter speeds can be set from 25 μ
s to
100 ms.
Electronic shutter:
Shutter speeds can be set from 60 μs to
100 ms.
Partial function 1 to 2048 lines 2 to 2048 lines 4 to 3072 lines (4-line increments)
Frame rate (Image
Acquisition T
ime
*1
)
118 fps (8.5 ms)
*2
38.9 fps (25.7 ms)
*2
Lens mounting C mount M42 mount
Field of vision, in-
stallation distance
Selecting a lens according to the field of vision and installation distance
Ambient tempera-
ture range
Operating: 0 to +40°C, Storage: -25 to +65°C (with no icing or condensation)
Ambient humidity
range
Operating and Storage: 35 to 85% (with no condensation)
Weight Approx. 110g Approx. 320g
Accessories
Instruction Sheet
*1. This image acquisition time does not include the image conversion processing time of the sensor controller.
*2. Frame rate in high speed mode when the camera is connected using two camera cables.
Model FH-SMX FH-SCX FH-SMX05 FH-SCX05 FH-SMX12 FH-SCX12
Image elements CMOS image elements
(1/2.9-inch equivalent)
CMOS image elements
(2/3-inch equivalent)
CMOS image elements
(1.1-inch equivalent)
Color/Monochrome Mono-
chrome
Color Mono-
chrome
Color Mono-
chrome
Color
Effective pixels 720 (H) x 540 (V) 2448 (H) x 2048 (V) 4092 (H) x 3000 (V)
Imaging area H x V
(opposing corner)
4.97 x 3.73 (6.21 mm) 8.45 x 7.07 (11.01 mm) 14.12 x 10.35 (17.50 mm)
Pixel size 6.9 (μm) x 6.9 (μm) 3.45 (μm) x 3.45 (μm) 3.45 (μm) x 3.45 (μm)
Shutter function Electronic shutter:
Shatter speeds can be set
from 1 μs to 100 ms.
Electronic shutter:
Shatter speeds can be set
from 1 μs to 100 ms.
Electronic shutter:
Shatter speeds can be set
from 1.5 μs to 100 ms.
Partial function 4 to 540 lines (4-line incre-
ments)
4 to 2048 lines (4-line incre-
ments)
4 to 3,000 lines (4-line in-
crements)
Frame rate (Image
Acquisition T
ime
*1
)
523.6 fps (1.9 ms)
*2
97.2 fps (10.3 ms)
*3
40.1 fps (24.9 ms)
*3
Lens mounting C mount
(Recommend 3Z4S-LE SV
-
V series)
C mount (Recommend
3Z4S-LE SV-H series)
C mount (Recommend
3Z4S-LE SV-LLD series)
Field of vision, in-
stallation distance
Selecting a lens according to the field of vision and installation distance
Ambient tempera-
ture range
Operating: 0 to +50°C, Stor-
age: -25 to +65°C (with no
icing or condensation)
Operating: 0 to +40°C, Storage: -25 to +65°C (with no
icing or condensation)
Ambient humidity
range
Operating and Storage: 35 to 85% (with no condensation)
Weight Approx. 48g Approx. 85g Approx. 85g
Accessories
Instruction Sheet
General Compliance Information and Instructions for EU
*1. This image acquisition time does not include the image conversion processing time of the sensor controller.
