Model FZ-SF FZ-SFC FZ-SP FZ-SPC
Imaging area H x V
(opposing corner)
4.8 x 3.6 (6 mm)
Pixel size 7.4 (μm) x 7.4 (μm)
Shutter function Electronic shutter:
Shutter speeds can be set from 20 μ
s to 100 ms.
Partial function 12 to 480 lines
Frame rate (Image
Acquisition T
ime
*1
)
80 fps (12.5 ms)
Lens mounting Special mount (M10.5 P0.5)
Field of vision, in-
stallation distance
Selecting a lens according to the field of vision and installation distance
Ambient tempera-
ture range
Operating of camera amp: 0 to +50°C, Operating of camera head: 0 to +45°C
Storage: -25 to +65°C (with no icing or condensation)
Ambient humidity
range
Operating and Storage: 35 to 85% (with no condensation)
Minimum bending
radius between
camera head and
camera amplifier
12.7 mm
Weight Approx. 150g
Accessories
• Instruction Sheet
• installation bracket
• Four mounting screws (M2 x 4)
• Instruction Sheet
*1. This image acquisition time does not include the image conversion processing time of the sensor controller.
Dimensions
l
Camera Head
a) Flat Camera: FZ-SF/-SFC
3 Configuration
3-34
FH Series Vision System Hardware Setup Manual (Z366-E1)
