Omron FQ2 Series Manual

FQ2
4
Field of view/Installation distance (Unit: mm)
Touch Finder
Note: AC Adapter and Battery are sold separately.
Cables
Sensor Data Unit
(FQ2-S3/S4 only)
Cables for Sensor Data Unit
* When using FQ-SDU@@ , 2 Cables are required for all I/O signals.
Field of view Narrow View Standard View Wide View (Long-distance) Wide View (Short-distance)
Appearance
350,000 pixels Type
Figure
1
Figure 2 Figure 3 Figure 4
760,000 pixels Type
Figure 5 Figure 6 Figure 7 Figure 8
13
8.2
Field of
view
7.5
38
57
4.7
5333
Field of
view
13
56
215
8.2
240
153
Field of
view
220
970
33
53
300
191
Field of
view
18
32
380
29
13
11.6
Field of
view
7.5
38
57
6.7
53
47.3
Field of
view
11.6
56
215
13
240
214
Field of
view
220
970
47.3
53
300
268
Field of
view
32
380
25.9
29
Type Appearance
Model
DC power supply FQ2-D30
AC/DC/battery FQ2-D31 (See note.)
Type Appearance
Cable
length
Model
FQ Ethernet Cables
(connect Sensor to Touch
Finder, Sensor to PC)
2m FQ-WN002
5m FQ-WN005
10m FQ-WN010
20m FQ-WN020
I/O Cables
2m FQ-WD002
5m FQ-WD005
10m FQ-WD010
20m FQ-WD020
Robotic
cable
Robotic
cable
Type Appearance Output type Model
Parallel Interface
NPN FQ-SDU10
PNP FQ-SDU15
RS-232C Interface
NPN FQ-SDU20
PNP FQ-SDU25
Type Appearance
Cable
length
Model
Sensor Data Unit Cable
2m FQ-WU002
5m FQ-WU005
10m FQ-WU010
20m FQ-WU020
Parallel Cable
for FQ-SDU1*
2m FQ-VP1002
5m FQ-VP1005
10m FQ-VP1010
Parallel Cable
for FQ-SDU2*
2m FQ-VP2002
5m FQ-VP2005
10m FQ-VP2010
RS-232C Cable
for FQ-SDU2
2m XW2Z-200S-V
5m XW2Z-500S-V
Robotic
cable

Omron FQ2 Series Specifications

General

Manufacturer	Omron
Type	Security Camera
Series	FQ2 Series
Sensor Type	CMOS
Communication Interface	Ethernet, RS-232C
Lens Mount	C-mount
Protection Structure	IP67
Category	Security Camera
