10.4 Gain
The gain has Analog Gain, Digital Gain.
Analog Gain
This parameter sets analog gain.
Selects “AnalogAll” at “GainSelector”, sets gain at “Gain”.
GenICam Parameters
GainSelector IEnumeration Type Selects control gain
AnalogAll: Analog Gain
Gain IFloat Type Analog Gain
Range: 0 (x1) or 1 (x4)
Default: 0
Digital Gain
This parameter sets digital gain.
Selects “DigitalAll” at “GainSelector”, sets gain at “Gain”.
GenICam Parameters
GainSelector IEnumeration Type Selects control gain
DigitalAll: Digital Gain
DigitalGain IFloat Type Digital Gain
Range: 0 to 255
Default: 0
Digital Gain Formula
Pixel level (brightness level) of image after applying digital gain =
(1 + “Digital Gain” / 64) * (brightness level - FFCOffsetTarget) + FFOffsetTarget
