Omron G3NA - Page 10

10 Solid State Relays G3NA
Y92B-P250 (for the G3NA-250B-UTU, G3NA-450B-UTU)
70 max.
Four, M4
Four, R2.5
130.5 max.
190.5 max.
Mounting Holes
Four, 4.5 dia. or M4
Two, M4
Depth10
47.6
Y92B-A100
Y92B-A150
47.6
50±0.1
47.6
50±0.1
56±0.5
R2.2
90±0.1
90±0.1
Y92B-A100 Low-cost
Heat Sink
(for the G3NA-205B-UTU,
G3NA-210B-UTU,
G3NA-220B-UTU,
G3NA-410B-UTU,
G3NA-425B-UTU,
G3NA-D210B)
Y92B-A150N Low-cost
Heat Sink
(for the G3NA-240B-UTU)
The orientation indicated by the external dimensions is not the correct mounting orientation. When opening mounting holes, refer to the
mounting hole dimensions.
For surface mounting, a 30% derating of the load current is required (from the Load Current vs. Ambient Temperature graphs).
Mounting Holes
Two, M4 holes
100 max.
Three, M4 holes
150 max.
Four, 4.3-dia. or M4 holes
Weight: approx. 210 g Weight: approx. 310 g
102 max.
80.5 max.
30
1.5
45.5 max.
1.5
9.6
2
