Solid State Relays G3NA 3
Specifications
■ Ratings
Input (at an Ambient Temperature of 25°C)
Note: 1. The input impedance is measured at the maximum value of the rated supply voltage (for example, with the model rated at 100 to 120 VAC,
the input impedance is measured at 120 VAC).
2. With constant current input circuit system.
3. Refer to Temperature Characteristics (for Must Operate Voltage and Must Release Voltage) in Engineering Data for further details.
Output
Note: 1. The load current varies depending on the ambient temperature. Refer to Load Current vs. Ambient Temperature under Engineering Data.
2. When an OMRON Heat Sink (refer to Options) or a heat sink of the specified size is used.
Model Rated voltage Operating voltage Impedance
(See note 1.)
Voltage level
Must operate voltage Must release voltage
G3NA-2@@B-UTU 5 to 24 VDC 4 to 32 VDC 15 mA max. (See note 2.) 4 VDC max. 1 VDC min.
100 to 120 VAC 75 to 132 VAC 36 k
Ω±20% 75 VAC max. (See note 3.) 20 VAC min. (See note 3.)
200 to 240 VAC 150 to 264 VAC 72 k
Ω±20% 150 VAC max. (See note 3.) 40 VAC min. (See note 3.)
G3NA-4@@B-UTU 5 to 24 VDC 4 to 32 VDC 7 mA max. (See note 2.) 4 VDC max. 1 VDC min.
100 to 240 VAC 75 to 264 VAC 72 k
Ω±20% 75 VAC max. 20 VAC min.
G3NA-275B-UTU
G3NA-290B-UTU
G3NA-475B-UTU
G3NA-490B-UTU
G3NA-D210B-UTU
5 to 24 VDC 4 to 32 VDC 15 mA max. (See note 2.) 4 VDC max. 1 VDC min.
100 to 240 VAC 75 to 264 VAC 72 k
Ω±20% 75 VAC max. 20 VAC min.
Model Applicable load
Rated load voltage Load voltage range Load current (See note 1.) Inrush current
With heat sink
(See note 2.)
Without heat sink
G3NA-205B-UTU 24 to 240 VAC 19 to 264 VAC 0.1 to 5 A (at 40
°C) 0.1 to 3 A (at 40°C) 60 A (60 Hz, 1 cycle)
G3NA-210B-UTU 0.1 to 10 A (at 40
°C) 0.1 to 4 A (at 40°C) 150 A (60 Hz, 1 cycle)
G3NA-410B-UTU 200 to 480 VAC 180 to 528 VAC 0.2 to 10 A (at 40
°C) 0.2 to 4 A (at 40°C)
G3NA-220B-UTU 24 to 240 VAC 19 to 264 VAC 0.1 to 20 A (at 40
°C) 0.1 to 4 A (at 40°C) 220 A (60 Hz, 1 cycle)
G3NA-425B-UTU 200 to 480 VAC 180 to 528 VAC 0.2 to 25 A (at 40
°C) 0.2 to 4 A (at 40°C)
G3NA-240B-UTU 24 to 240 VAC 19 to 264 VAC 0.1 to 40 A (at 40
°C) 0.1 to 6 A (at 40°C) 440 A (60 Hz, 1 cycle)
G3NA-250B-UTU 24 to 240 VAC 19 to 264 VAC 0.1 to 50 A (at 40
°C) 0.1 to 6 A (at 40°C)
G3NA-450B-UTU 200 to 480 VAC 180 to 528 VAC 0.2 to 50 A (at 40
°C) 0.2 to 6 A (at 40°C)
G3NA-275B-UTU 24 to 240 VAC 19 to 264 VAC 1 to 75 A (at 40
°C) 1 to 7 A (at 40°C) 800 A (60 Hz, 1 cycle)
G3NA-475B-UTU 200 to 480 VAC 180 to 528 VAC 1 to 75 A (at 40
°C) 1 to 7 A (at 40°C) 800 A (60 Hz, 1 cycle)
G3NA-290B-UTU 24 to 240 VAC 19 to 264 VAC 1 to 90 A (at 40
°C) 1 to 7 A (at 40°C) 1,000 A (60 Hz, 1 cycle)
G3NA-490B-UTU 200 to 480 VAC 180 to 528 VAC 1 to 90 A (at 40
°C) 1 to 7 A (at 40°C) 1,000 A (60 Hz, 1 cycle)
G3NA-D210B-UTU 5 to 200 VDC 4 to 220 VDC 0.1 to 10 A (at 40
°C) 0.1 to 4 A (at 40°C) 20 A (10 ms)
