2 Solid State Relays G3NA
Ordering Information
■ List of Models
*All models are certified by UL, CSA, and TÜV.
Note: 1. The applicable output load depends on the ambient temperature. Refer to Load Current vs. Ambient Temperature in Engineering Data.
2. Loss time increases under 75 VAC. (Refer to page 13.) Confirm operation with the actual load.
■ Accessories (Order Separately)
One-touch Mounting Plates Mounting Bracket
Heat Sinks
Slim Models Enabling DIN-track Mounting Low-cost Models
Isolation Zero cross
function
Indicator Applicable output load
(See note 1.)
Rated input voltage Model
Phototriac Yes Yes 5 A at 24 to 240 VAC
(See note 2.)
5 to 24 VDC G3NA-205B-UTU DC5-24
Photocoupler 100 to 120 VAC G3NA-205B-UTU AC100-120
200 to 240 VAC G3NA-205B-UTU AC200-240
Phototriac 10 A at 24 to 240 VAC
(See note 2.)
5 to 24 VDC G3NA-210B-UTU DC5-24
Photocoupler 100 to 120 VAC G3NA-210B-UTU AC100-120
200 to 240 VAC G3NA-210B-UTU AC200-240
Phototriac 20 A at 24 to 240 VAC
(See note 2.)
5 to 24 VDC G3NA-220B-UTU DC5-24
Photocoupler 100 to 120 VAC G3NA-220B-UTU AC100-120
200 to 240 VAC G3NA-220B-UTU AC200-240
Phototriac 40 A at 24 to 240 VAC
(See note 2.)
5 to 24 VDC G3NA-240B-UTU DC5-24
Photocoupler 100 to 120 VAC G3NA-240B-UTU AC100-120
200 to 240 VAC G3NA-240B-UTU AC200-240
Phototriac 50 A at 24 to 240 VAC
(See note.)
5 to 24 VDC G3NA-250B-UTU DC5-24
Photocoupler 100 to 120 VAC G3NA-250B-UTU AC100-120
200 to 240 VAC G3NA-250B-UTU AC200-240
Phototriac 75 A at 24 to 240 VAC
(See note 2.)
5 to 24 VDC G3NA-275B-UTU DC5-24
Photocoupler 100 to 240 VAC G3NA-275B-UTU AC100-240
Phototriac 90 A at 24 to 240 VAC
(See note 2.)
5 to 24 VDC G3NA-290B-UTU DC5-24
Photocoupler 100 to 240 VAC G3NA-290B-UTU AC100-240
10 A at 200 to 480 VAC 5 to 24 VDC G3NA-410B-UTU DC5-24
100 to 240 VAC G3NA-410B-UTU AC100-240
25 A at 200 to 480 VAC 5 to 24 VDC G3NA-425B-UTU DC5-24
100 to 240 VAC G3NA-425B-UTU AC100-240
50 A at 200 to 480 VAC 5 to 24 VDC G3NA-450B-UTU DC5-24
100 to 240 VAC G3NA-450B-UTU AC100-240
75 A at 200 to 480 VAC
(See note 2.)
5 to 24 VDC G3NA-475B-UTU DC5-24
100 to 240 VAC G3NA-475B-UTU AC100-240
90 A at 200 to 480 VAC
(See note 2.)
5 to 24 VDC G3NA-490B-UTU DC5-24
100 to 240 VAC G3NA-490B-UTU AC100-240
--- 10 A at 5 to 200 VDC 5 to 24 VDC G3NA-D210B-UTU DC5-24
100 to 240 VAC G3NA-D210B-UTU AC100-240
Model
R99-12 FOR G3NA
Model Applicable SSR
R99-11 G3NA-240B-UTU, G3NA-250B-UTU, G3NA-450B-UTU
Model Applicable SSR
Y92B-N50 G3NA-205B-UTU, G3NA-210B-UTU,
G3NA-D210B-UTU, G3NA-410B-UTU
Y92B-N100 G3NA-220B-UTU, G3NA-425B-UTU
Y92B-N150 G3NA-240B-UTU, G3NA-250B-UTU
Y92B-P250 G3NA-450B-UTU
Y92B-P250NF G3NA-275B-UTU, G3NA-290B-UTU,
G3NA-475B-UTU, G3NA-490B-UTU
Model Applicable SSR
Y92B-A100 G3NA-205B-UTU, G3NA-210B-UTU,
G3NA-D210B-UTU, G3NA-220B-UTU,
G3NA-410B-UTU, G3NA-425B-UTU
Y92B-A150N G3NA-240-B-UTU

Omron G3NA Specifications

General

Category	Solid State Relay
Mounting Type	Panel Mount
Control Voltage	5-24V DC
Output Type	AC
Dielectric Strength	2500V AC
Load Voltage	24 – 240 VAC
