Omron G3PA - G3 PA Technical Specifications; Input Voltage and Current Specifications; Output Load and Inrush Current Ratings

Solid State Relays G3PA J-23
SSR
Specifications
■ Ratings (at an Ambient Temperature of 25°C)
Input
Output
Refer to Engineering Data for further details.
Model Rated voltage Operating Voltage
range
Input current
impedance
Voltage level
Must operate voltage Must release voltage
G3PA-210B-VD 5 to 24 VDC 4 to 30 VDC 7 mA max. 4 VDC max. 1 VDC min.
G3PA-220B-VD
G3PA-240B-VD
G3PA-260B-VD
G3PA-210BL-VD 5 to 24 VDC 4 to 30 VDC 20 mA max. 4 VDC max. 1 VDC min.
G3PA-220BL-VD
G3PA-240BL-VD
G3PA-260BL-VD
G3PA-210B-VD 24 VAC 19.2 to 26.4 VAC 1.4 kΩ±20% 19.2 VAC max. 4.8 VAC min.
G3PA-220B-VD
G3PA-240B-VD
G3PA-260B-VD
G3PA-420B-VD 12 to 24 VDC 9.6 to 30 VDC 7 mA max. 9.2 VDC max. 1 VDC min.
G3PA-430B-VD
G3PA-420B-VD-2
G3PA-430B-VD-2
G3PA-450B-VD-2
Model Applicable load
Rated load voltage Load voltage range Load current Inrush current
G3PA-210B(L)-VD 24 to 240 VAC (50/60 Hz) 19 to 264 VAC (50/60 Hz) 0.1 to 10 A 150 A (60 Hz, 1 cycle)
G3PA-220B(L)-VD 0.1 to 20 A 220 A (60 Hz, 1 cycle)
G3PA-240B(L)-VD 0.5 to 40 A 440 A (60 Hz, 1 cycle)
G3PA-260B(L)-VD 0.5 to 60 A 440 A (60 Hz, 1 cycle)
G3PA-420B-VD 180 to 400 VAC (50/60 Hz) 150 to 440 VAC (50/60 Hz) 0.5 to 20 A 220 A (60 Hz, 1 cycle)
G3PA-430B-VD 0.5 to 30 A 440 A (60 Hz, 1 cycle)
G3PA-420B-VD-2 200 to 480 VAC (50/60 Hz) 180 to 528 VAC (50/60 Hz) 0.5 to 20 A 220 A (60 Hz, 1 cycle)
G3PA-430B-VD-2 0.5 to 30 A 440 A (60 Hz, 1 cycle)
G3PA-450B-VD-2 0.5 to 50 A 440 A (60 Hz, 1 cycle)
