Omron G3PA User Manual

J-28 Solid State Relays G3PA
Engineering Data
Load Current vs. Ambient Temperature
Note: Close mounting is possible for a maximum of three Units by reducing the load current by 20%. (A minimum clearance of 10 mm must be
provided when mounting four or more Units.)
25
15
40 60 80 100200-20-30
60
40
25
20
80
Panel
Ground
Ambient temperature (°C) Ambient temperature (°C) Ambient temperature (°C)
Load current (A) Load current (A) Load current (A)
Vertical Mounting
G3PA-240B(L)-VD G3PA-260B(L)-VD
G3PA-220B(L)-VD
G3PA-210B(L)-VD
G3PA-210B(L)-VD, G3PA-220B(L)-VD
Ambient temperature (°C) Ambient temperature (°C)
Load current (A) Load current (A)
G3PA-430B-VD, G3PA-430B-VD-2G3PA-420B-VD, G3PA-420B-VD-2 G3PA-450B-VD-2
Ambient temperature (°C)
Load current (A)
