446 Single-phase Solid State Relays for Heaters G3PE
Specifications
■ Ratings
Input (at an Ambient Temperature of 25°C)
Output
* The applicable load current depends on the ambient temperature. For details, refer to Load Current vs. Ambient Temperature
■ Characteristics
Item
Model
Rated voltage Operating voltage range Rated input current
Voltage level
Must operate voltage Must release voltage
G3PE-@@@B 12 to 24 VDC 9.6 to 30 VDC 7 mA max. 9.6 VDC max. 1.0 VDC max.
G3PE-@@@BL 15 mA max.
Model
G3PE-215B(L) G3PE-225B(L) G3PE-235B(L) G3PE-245B(L)
Item
Rated load voltage 100 to 240 VAC (50/60 Hz)
Load voltage range 75 to 264 VAC (50/60 Hz)
Applicable load current * 0.1 to 15 A
(at 40°C)
0.1 to 25 A
(at 40°C)
0.5 to 35 A
(at 25°C)
0.5 to 45 A
(at 25°C)
Inrush current 150 A
(60 Hz, 1 cycle)
220 A
(60 Hz, 1 cycle)
440 A
(60 Hz, 1 cycle)
Permissible I
2
t
(reference value)
121A
2
s 260A
2
s 1,260A
2
s
Applicable load
(resistive load)
3 kW
(at 200 VAC)
5 kW
(at 200 VAC)
7 kW
(at 200 VAC)
9 kW
(at 200 VAC)
Model
G3PE-215B G3PE-225B G3PE-235B G3PE-245B G3PE-215BL G3PE-225BL G3PE-235BL G3PE-245BL
Item
Operate time 1/2 of load power source cycle + 1 ms max. 1 ms max.
Release time 1/2 of load power source cycle + 1 ms max.
Output ON voltage drop 1.6 V (RMS) max.
Leakage current 10 mA max. (at 200 VAC)
Insulation resistance 100 MΩ min. (at 500 VDC)
Dielectric strength 2,500 VAC, 50/60 Hz for 1 min
Vibration resistance 10 to 55 to10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude) (Mounted to DIN track)
Shock resistance
Destruction: 294 m/s
2
(Mounted to DIN track)
Ambient storage temperature −30 to 100°C (with no icing or condensation)
Ambient operating
temperature
−30 to 80°C (with no icing or condensation)
Ambient operating humidity 45% to 85%
Weight Approx. 240 g Approx. 400 g Approx. 240 g Approx. 400 g
