Single-phase Solid State Relays for Heaters G3PE 447
Engineering Data
Input Voltage vs. Input Impedance and Input Voltage vs. Input Current
G3PE-2@@BG3PE-2@@BL
10
9
8
7
6
5
4
3
2
1
0
0 5 10 15 20 25 30 35
Input voltage (V)
Input current
Input impedance
Input current (mA)
Input impedance (kΩ)
Ta = 25°C
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0 5 10 15 20 25 30 35
Input voltage (V)
Input current
Input impedance
Input current (mA)
Input impedance (kΩ)
Ta = 25°C
Load Current vs. Ambient Temperature
G3PE-215B(L), G3PE-225B(L) G3PE-235B(L), G3PE-245B(L)
30
25
20
15
10
7
0
Load current (A)
−30 −20 0 20 40 60 80 100
Ambient temperature (°C)
G3PE-@25B(L)
G3PE-@15B(L)
−30 −20 0 20 40 60 80 100
18
17
14
25
50
45
40
35
30
20
10
0
G3PE-245B(L)
G3PE-235B(L)
Load current (A)
Ambient temperature (°C)
Inrush Current Resistivity: Non-repetitive
Make sure the inrush current stays below the dashed line curve if it occurs repetitively.
G3PE-215B(L) G3PE-225B(L)
G3PE-235B(L), G3PE-245B(L)
250
200
150
100
50
0
Inrush current (A. Peak)
Energized time (ms)
10 30 50 100 300 500 1,000 3,000 5,000
250
200
150
100
50
0
10 30 50 100 300 500 1,000 3,000 5,000
Inrush current (A. Peak)
Energized time (ms)
500
400
300
200
100
0
10 30 50
100 300 500 1,000 3,000 5,000
Inrush current (A. Peak)
Energized time (ms)
