Omron H5BR Series - Operational Overview

H5BR
H5BR
6
Operational Overview
Run mode
Present value,
set value
Batch count value,
set value
Timing range
Key protect level
Input signal time
Output time
Output mode
UP/DOWN mode
Setting mode
Press the
DISPLAY key
Press the
BATCH key
Press the
DISPLAY key
Press the
MODE key
Press the
MODE key
Press the
MODE key
Press the
MODE key
Press the
MODE key
Press the
MODE key
Press the
MODE key
Note: 1. Set values are changed using the increment keys
(1 to 4).
2. The large arrows indicate the parameter displayed first
when the mode is changed with the MODE or DISPLAY
key.
