Omron H7CR-B Series

H7CR
H7CR
22
Model H7CR-A (Economy type) H7CR-B (Standard type) H7CR-C (+/– Range type) H7CR-8, -11 (Socket)
Present value 0 0 0 0
Presets 0 0 0 0
Input modes Up Up Reversible C Up
(phase difference)
Output mode N N (hold outputs on preset 1 K N
for double preset)
Output 2 time HOLD HOLD 500 ms HOLD
Output 1 time — HOLD 500 ms —
Counting speeds 30 cps 30 cps 30 cps 30 cps
Min. reset time 20 ms (not adjustable) 20 ms 20 ms 20 ms
Decimal point Not applicable Far right (no fractions) Far right (no fractions) Far right (no fractions)
Scale factor 1.000 (not adjustable) 1.000 1.000 1.000
Key protection level — KP-1 KP-1 KP-1 (H7CR-11 only)
■ FACTORY SETTINGS
The following settings are made at the factory. Be sure to
change any settings before operating the counter. Settings and
display are possible with or without power supplied, although
power supply is required for inputs and outputs to operate.
Model H7CR-A (Economy type) H7CR-B (Standard type) H7CR-C (+/– Range type)
Present value 0 0 0
Presets 0 0 0
Input modes Up Up Reversible C
(phase difference)
Output mode N N (hold outputs on preset 1 K
for double preset)
Output 2 time HOLD HOLD 500 ms
Output 1 time — HOLD 500 ms
Counting speeds 30 cps 30 cps 30 cps
Min. reset time 20 ms (not adjustable) 20 ms 20 ms
Decimal point Not applicable Far right (no fractions) Far right (no fractions)
Scale factor 1.000 (not adjustable) 1.000 1.000
Key protection level — KP-1 KP-1
H7CR-A, H7CR-B, H7CR-C
H7CR-S, H7CR-8, H7CR-11
Outputs are not possible with the presets set to zero. The
display and settings are powered by an internal battery so they
are unaffected by external power interruptions.
