H7CR
H7CR
2
Model Economy Standard Reversible +/– Range
Number of presets One One Two One Two
Display type 6-digit, not backlit 6-digit, backlit 4-digit, backlit 6-digit, backlit 6-digit backlit
Input type No-voltage
Contact output H7CR-SAL H7CR-SBL H7CR-SB4L — H7CR-SCL —
Transistor H7CR-SASL H7CR-SBSL — H7CR-SBWSL H7CR-SCSL H7CR-SCWSL
Counter supply voltage 12 to 24 VDC
■ REVERSIBLE +/– RANGE COUNTERS
Number of presets One Two (Non-independent)
Display type 6-digit LCD, backlit 6-digit LCD, backlit
Input type No-voltage Voltage No-voltage Voltage
Contact output H7CR-C H7CR-CV H7CR-CW H7CR-CWV
Transistor output H7CR-CS H7CR-CVS H7CR-CWS H7CR-CWVS
Contact output H7CR-CG H7CR-CVG H7CR-CWG H7CR-CWVG
Transistor output H7CR-CSG H7CR-CVSG H7CR-CWSG H7CR-CWVSG
Counter supply voltages 100 to 240 VAC, 50/60 Hz or 24 VAC/12 to 24 VDC
■ SHORT BODY COUNTERS
■ SOCKET-MOUNT COUNTERS
Number of presets One
Display type 6-digit LCD, backlit 4-digit LCD, backlit 6-digit LCD, backlit
Input type Power supply reset type Memory backup type
Contact output H7CR-8 H7CR-84* H7CR-11
Transistor H7CR-8S — H7CR-11S
Counter supply voltage 100 to 240 VAC, 50/60 Hz or 24 VAC/12 to 24 VDC
* Available with 100 to 240 VAC supply voltage only.
■ ACCESSORIES
12 VDC sensor
supply voltage
24 VDC sensor
supply voltage
Description Part number
Sockets 11-pin Bottom surface or track mounting, top screw terminals P2CF-11
Bottom surface or track mounting, top screw terminals, finger safe terminal P2CF-11-E
conforms to VDE0106/P100
Back mounting, for use with Y92F-30 mounting adapter, bottom screw terminals P3GA-11
8-pin Bottom surface or track mounting, top screw terminals P2CF-08
Bottom surface or track mounting, top screw terminals, finger safe terminal P2CF-08-E
conforms to VDE0106/P100
Back mounting, for use with Y92F-30 mounting adapter, bottom screw terminals P3G-08
Terminal cover for P3G sockets, conforms to VDE0106/P100 Y92A-48G
Panel mounting adapter Fits behind panel, ideal for side-by-side installation. Use P3G-08 sockets Y92F-30
Protective cover Hard plastic cover protects against dust, dirt and water; not for use with Y92A-48B
panel covers
Soft cover with two mounting clips for front panel protection Y92A-48F1
Shock prevention terminal cover protects wiring connections Y92A-48T
NEMA 4 cover Waterproof front cover Y92A-48N
Mounting track DIN rail, 50 cm (1.64 ft) length; 7.3 mm thick PFP-50N
DIN rail, 1 m (3.28 ft) length; 7.3 mm thick PFP-100N
DIN rail, 1 m (3.28 ft) length; 16 mm thick PFP-110N2
End plate PFP-M
Spacer PFP-S
* Panel mounting adapter is included with H7CR-A/-B/-C digital counters.
Order separately for use with H7CR-8/-11 counters.
