Omron H7CZ-L8

H7CZ
2
Model Number Structure
Model Number Legend
H7CZ-L@@
12
Ordering Information
List of Models
Note: The functions that are provided depend on the model. Check detailed specifications before ordering.
Accessories (Order Separately)
Soft Cover
Hard Cover
Flush Mounting Adapter
Waterproof Packing
Connection Sockets
Terminal Covers for P3G-08 Back-connecting Socket
Type Configuration
External
connections
Settings
Display
digits
Outputs
Power supply
voltage
Model
H7CZ
• 1-stage preset
counter
8-pin socket 1-stage 6 digits Contact output (SPDT)
100 to 240 VAC H7CZ-L8
12 to 24 VDC/24 VAC H7CZ-L8D1
Model Page
Y92A-48F1 9
Model Page
Y92A-48 9
Model Page
Y92F-30 9
Model Page
Y92S-29 9
Model Type Remarks Page
P2CF-08 Front-connecting Socket ---
10
P2CF-08-E Front-connecting Socket (Finger-safe Type)
Round crimp terminals cannot be used on
Finger-safe Sockets.
Use forked crimp terminals.
P3G-08 Back-connecting Sockets
A Y92A-48G Terminal Cover can be used with
the Socket to create a finger-safe construction.
Model Page
Y92A-48G 10
1. External connections 2. Supply voltage
Symbol Meaning
8 8-pin socket
Symbol Meaning
None 100 to 240 VAC at 50/60 Hz
D1 12 to 24 VDC/24 VAC at 50/60 Hz
