Omron H7CZ-L8

6
H7CZ
Nomenclature
Dimensions (Unit: mm)
Counters
Dimensions with Front Connecting Socket
* These dimensions depend on the kind of DIN Track. (Reference value)
ON
(Enable)
(Default setting) OFF
(Disable)
1 6
Display Section
3. Reset Indicator
1. Key Protect Indicator
2. Control Output Indicator
5. Set value (Sub-display)
(Character height: 6 mm)
Operation Keys
6. Mode Key
(Changes modes and setting items.)
7. Reset Key
8. Up Keys to
Switches
9. Key-protect Switch
4. Present Value (Main Display)
(Character height: 10 mm)
6
7
5
4
8
1st digit 6th digit
1
2
3
9
10 mm
6 mm
Character Size
for Sub-display
Character Size
for Main Display
63.7
14.2
6
44.8×44.8
48 × 48
H7CZ-L8/-L8D1 (Flush Mounting/Surface Mounting Models)
Panel Cutouts
Panel cutouts are as shown below. (according
to DIN43700).
Note: 1. The mounting panel thickness
should be 1 to 5 mm.
2. To allow easier operation, it is
recommended that Adapters be
mounted so that the gap between
sides with hooks is at least 15 mm
(i.e., with the panel cutouts
separated by at least 60 mm).
3. It is possible to horizontally mount
Timers side by side. Attach the
Flush Mounting Adapters so that
the surfaces without hooks are on
the sides of the Timers. If they are
mounted side-by-side, water-
resistance will be lost.
60 min.
60 min.
15 min.
45
+
0.6
0
45
+
0.6
0
A
With Y92A-48F1 attached.
With Y92A-48 attached.
A=(48n−2.5)
+1
−0
A=(51n−5.5)
+1
−0
A={48n−2.5+(n−1)×4}
+1
−0
n Units mounted
side by side
58
48
84.87.5
(51)
Y92F-30 (order separately)
Flush Mounting Adapter
P3G-08 (order
separately)
Back-connecting
Socket
PanelY92S-29 (order separately)
Waterproof Packing
Dimensions with Flush Mounting Adapter
H7CZ-L8/-L8D1 (Adapter and Waterproof Packing Ordered Separately)
H7CZ
-L8@
P2CF-08(-E) (order separately)
Front Connecting Socket
92.3
90
*
