H7CZ
8
Connection Sockets
Front Connecting Socket
Note: Round crimp terminals cannot be used on Finger-safe Sockets. Use forked crimp terminals.
Back-connecting Sockets
Note: A Y92A-48G Terminal Cover can be used with the Socket to create a finger-safe construction.
Terminal Covers for P3G-08 Back-connecting Socket
Note: The Terminal Cover can be used with a Back-mounting Socket (P3G-08) to create a finger-safe construction.
Model Dimensions
Terminal arrangement
and internal connections
Mounting hole
dimensions
P2CF-08
(Top View)
Note: The Socket can
also be mounted
to DIN track.
P2CF-08-E
(Finger Safe Terminal)
Model Dimensions
Terminal arrangement
and internal connections
P3G-08
(Bottom View)
Model Dimensions
Y92A-48G
4
70 max.
Two, 4.5-dia. holes
Eight, M3.5 x 7.5 sems screws
7.8
20.3 max.
4.5
3
50 max.
35.4
6 5 4 3
7 8 1 2
40
±0.2
Two, M4 or 4.5-dia. holes
1278
4365
P2CF-08-E
10A250VAC
RESISTIVE
4
70 max.
Two, 4.5-dia. holes
Eight, M3.5 x 7.5 set screws
7.8
21.5 max.
20.3
19
4.5
35.4
1.3
3
5
50 max.
40
±0.2
27 dia.
4.9 17
45
45
6543
7812
Y92A-48G
UP
P C
34
Twelve, 6.4-dia. holes
47.7 × 47.7
48 × 48
27.6
24.6
16.5
47.4
