Omron HEM-432C User Manual

BATTERY INSTALLATION
1. Press the s indicator on the
battery cover and slide the cover
off in the direction of the arrow.
2. Install 4 “AAA” size batteries so
the + (positive) and - (negative)
polarities match the polarities of
the battery compartment as indicated.
3. Replace the battery cover.
BATTERY REPLACEMENT
Low Battery Indicator
When the Low Battery Symbol appears on the display screen remove
all the batteries. Replace with four new batteries at the same time.
When the Low Battery Symbol blinks a brief period of usage remains.
Long life alkaline batteries are recommended.
NOTES:
• Measurement values stored in the memory will not be deleted
during battery replacement.
• After replacing the batteries, reset the date and time.
Refer to page 9, Setting the Date and Time.
• Dispose of batteries according to applicable local regulations.
8
FINAL.HEM-432CN2-IM 2/23/10 10:56 AM Page 8

Omron HEM-432C Specifications

Measurement Specifications

pressure measurement range	0 - 280 mmHg
pulse measurement range	40 - 200/minute
pressure accuracy	±3 mmHg or 2 % of reading
pulse accuracy	±5% of reading

Operating Environment

operating temperature	50°F to 104°F (10°C to 40°C)
operating humidity	30 to 85% RH maximum
storage temperature	-4°F to 140°F (-20°C to 60°C)
storage humidity	10 to 95% RH maximum

Power

power source	4 “AAA” batteries
battery usage	Approx. 300 usages

Weight and Dimensions

unit weight	1.0 lbs
unit dimensions	5.13" x 3.5" x 6.88"
master weight	14.25 lbs
master dimensions	22" x 11" x 8.25"
monitor weight	Approximately 8 oz (225 g)
cuff size	Approximately 5 1/2" x 18 7/8" (140 mm x 480 mm)
cuff circumference	9" to 13" (229 mm x 330 mm)
