20 Digital Indicators K3HB-R/-P/-C
Common Specifications
■ Event Input Ratings
■ Output Ratings
Contact Output Transistor Outputs
Linear Output
Serial Communications Output BCD Output I/O Ratings
(Input Signal Logic: Negative)
K3HB-R S-TMR, HOLD, RESET, BANK1, BANK2, BANK4
K3HB-P/-C HOLD, RESET, BANK1, BANK2, BANK4
Contact ON: 1 kΩ max., OFF: 100 kΩ min.
No-contact
ON residual voltage: 2 V max.
OFF leakage current: 0.1 mA max.
Load current: 4 mA max.
Maximum applied voltage: 30 VDC max.
Item
Resistive loads
(250 VAC, cos
φ=1;
30 VDC, L/R=0 ms)
Inductive loads
(250 VAC, closed
circuit, cos
φ=0.4;
30 VDC, L/R=7 ms)
Rated load 5 A at 250 VAC
5 A at 30 VDC
1 A at 250 VAC
1 A at 30 VDC
Rated through
current
5 A
Mechanical life
expectancy
5,000,000 operations
Electrical life
expectancy
100,000 operations
Maximum load voltage 24 VDC
Maximum load current 50 mA
Leakage current 100
µA max.
Item Outputs 0 to 20 mA 4 to 20 mA 0 to 5 V 1 to 5 V 0 to 10 V
Allowable load impedance 500
Ω max. 5 kΩ min.
Resolution Approx. 10,000
Output error ±0.5% FS ±0.5% FS
(±0.15 V for 1 V or less and no output for 0 V)
Item Type RS-232C, RS-485
Communications method Half duplex
Synchronization method Start-stop synchronization (asynchronous)
Baud rate 9600/19200/38400 bps
Transmission code ASCII
Data length 7 bits or 8 bits
Stop bit length 2 bits or 1 bit
Error detection Vertical parity and FCS
Parity check Odd, even
I/O signal name Item Rating
Inputs K3HB-R/P
REQUEST
HOLD
MAX
MIN
RESET
K3HB-C
REQUEST
COMPEN-
SATION
RESET
Input signal No-voltage
contact input
Input current for
no-voltage input
10 mA
Signal
level
ON voltage 1.5 V max.
OFF voltage 3 V min.
Outputs DATA
POLARITY
OVER
DATA VALID
RUN
Maximum load
voltage
24 VDC
Maximum load
current
10 mA
Leakage current 100
µA max.
K3HB-R/P
HH
H
PAS S
L
LL
K3HB-C
OUT1
OUT2
OUT3
OUT4
OUT5
Maximum load
voltage
24 VDC
Maximum load
current
50 mA
Leakage current 100
µA max.
Refer to the K3HB Communications User's Manual (Cat. No. N129)
for details on serial and DeviceNet communications.

Omron K3HB-R Specifications

General

Brand	Omron
Model	K3HB-R
Category	Measuring Instruments
Language	English
