Omron NJ Series Troubleshooting Manual

3 Error Tables
3-40
NJ-series Troubleshooting Manual (W503)
54015496 hex Master Axis Gear
Ratio Numerator
Out of Range
The parameter specified for
the RatioNumeratorMaster
input variable to a motion
control instruction is out of
range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S NJ-series
Instruc-
tions Ref-
erence
Manual
(Cat. No.
W502)
54015497 hex Master Axis Gear
Ratio Denomina-
tor Out of Range
The parameter specified for
the RatioDenominatorMas-
ter input variable to a
motion control instruction is
out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015498 hex Auxiliary Axis Gear
Ratio Numerator
Out of Range
The parameter specified for
the RatioNumeratorAuxil-
iary input variable to a
motion control instruction is
out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015499 hex Auxiliary Axis Gear
Ratio Denomina-
tor Out of Range
The parameter specified for
the RatioDenominatorAuxil-
iary input variable to a
motion control instruction is
out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401549A hex Master Axis Posi-
tion Type Selec-
tion Out of Range
The parameter specified for
the ReferenceTypeMaster
input variable to a motion
control instruction is out of
range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401549B hex Auxiliary Axis Posi-
tion Type Selec-
tion Out of Range
The parameter specified for
the ReferenceTypeAuxil-
iary input variable to a
motion control instruction is
out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401549C hex Target Position
Ring Counter Out
of Range
Oper
ation is not possible
because the target position
is out of range for the ring
counter of the executed
instruction.
• High-speed homing
was executed when 0
was not included in
the ring counter.
S Same as
above.
5401549D hex
(Ver. 1.01)
Axes Group Com-
position Axis Set-
ting Out of Range
The parameter specified for
the Axes input variable to a
motion control instruction is
out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401549E hex
(Ver. 1.04)
Axis Use Setting
Out of Range
The parameter specified for
the AxisUse input variable
to a motion control instruc-
tion is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015700 hex
(Ver. 1.03)
Homing Parame-
ter Setting Out of
Range
The parameter specified for
the HomingParameter input
variable to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015702 hex
(Ver. 1.04)
Axis Use Change
Error
The MC_ChangeAxisUse
(Change Axis Use) instruc-
tion was executed when the
axis was not stopped or
when the command veloc-
ity of the axis was satu-
rated.
• The
MC_ChangeAxisUse
(Change Axis Use)
instruction was exe-
cuted when the axis
was not stopped or
when the command
velocity of the axis
was saturated.
S Same as
above.
