3 Error Tables
3-42
NJ-series Troubleshooting Manual (W503)
54015723 hex
(Ver. 1.06)
Switch Structure
Track Number Set-
ting Out of Range
The value of TrackNumber
that is specified in the
Switches in-out variable to
a motion control instruction
is out of range.
• The value of the mem-
ber of the structure
variable that was
specified for the in-out
variable of the instruc-
tion is out of range.
S NJ-series
Instruc-
tions Ref-
erence
Manual
(Cat. No.
W502)
54015724 hex
(Ver. 1.06)
Switch Structure
First ON Position
Setting Out of
Range
The value of FirstOnPosi-
tion that is specified in the
Switches in-out variable to
a motion control instruction
is out of range.
• The value of the mem-
ber of the structure
variable that was
specified for the in-out
variable of the instruc-
tion is out of range.
S Same as
above.
54015725 hex
(Ver. 1.06)
Switch Structure
Last ON Position
Setting Out of
Range
The value of LastOnPosi-
tion that is specified in the
Switches in-out variable to
a motion control instruction
is out of range.
• The value of the mem-
ber of the structure
variable that was
specified for the in-out
variable of the instruc-
tion is out of range.
S Same as
above.
54015726 hex
(Ver. 1.06)
Switch Structure
Axis Direction Out
of Range
The value of AxisDirection
that is specified in the
Switches in-out variable to
a motion control instruction
is out of range.
• The value of the mem-
ber of the structure
variable that was
specified for the in-out
variable of the instruc-
tion is out of range.
S Same as
above.
54015727 hex
(Ver. 1.06)
Switch Structure
Cam Switch Mode
Out of Range
The value of CamSwitch-
Mode that is specified in
the Switches in-out variable
to a motion control instruc-
tion is out of range.
• The value of the mem-
ber of the structure
variable that was
sp
ecified for the
in-out
variable of the instruc-
tion is out of range.
S Same as
above.
54015728 hex
(Ver. 1.06)
Switch Structure
Duration Setting
Out of Range
The value of Duration that
is specified in the Switches
in-out variable to a motion
control instruction is out of
range.
• The value of the mem-
ber of the structure
variable that was
specified for the in-out
variable of the instruc-
tion is out of range.
S Same as
above.
54015729 hex
(Ver. 1.06)
Track Option Struc-
ture ON Compen-
sation Setting Out
of Range
The value of OnCompensa-
tion that is specified in the
TrackOptions in-out vari-
able to a motion control
instruction is out of range.
• The value of the mem-
ber of the structure
variable that was
specified for the in-out
variable of the instruc-
tion is out of range.
S Same as
above.
5401572A hex
(Ver. 1.06)
Track Option Struc-
ture OFF Compen-
sation Setting Out
of Range
The value of OffCompensa-
tion that is specified in the
TrackOptions in-out vari-
able to a motion control
instruction is out of range.
• The value of the mem-
ber of the structure
variable that was
specified for the in-out
variable of the instruc-
tion is out of range.
S Same as
above.
5401572B hex
(Ver. 1.06)
Number of Array
Elements in Switch
Structure Variable
Out of Range
The number of elements in
an array in the structure
variable that is specified in
the Switches in-out variable
to a motion control instruc-
tion is out of range.
• The number of ele-
ments in an array of
the structure variable
that was specified for
the in-out variable of
the instruction is out of
range.
S Same as
above.
5401572C hex
(Ver. 1.06)
Number of Array
Elements in Output
Signal Structure
Variable Out of
Range
The number of elements in
an array in the structure
variable that is specified in
the Outputs in-out variable
to a motion control instruc-
tion is out of range.
• The n
umber of ele-
ments in a
n array of
the structure variable
that was specified for
the in-out variable of
the instruction is out of
range.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Refer-
ence
Maj Prt Min Obs Info
