Omron NJ Series Troubleshooting Manual

3 Error Tables
3-60
NJ-series Troubleshooting Manual (W503)
544F0000 hex Setting Out of
Range for
Writing MC
Setting
The parameter
specified for the
SettingValue input
variable to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
• The parameter specification
and the data type of the setting
value do not agree.
S NJ-series
Motion Con-
trol Instruc-
tions
Reference
Manual (Cat.
No. W508)
54500000 hex Trigger Input
Condition
Mode Selec-
tion Out of
Range
The parameter
specified for the
TriggerInput:: Mode
input variable to a
motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54510000 hex Drive Trigger
Signal Selec-
tion Out of
Range for
Trigger Input
Condition
The parameter
specified for the
TriggerInput::Input-
Drive input variable
to a motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54530000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(Axis Specifi-
cation)
An attempt was
made to change the
parameter for the
Axis input variable
when re-executing
a motion control
instruction. (This
input variable can-
not be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S Same as
above.
54540000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(Buffer Mode
Selection)
An attempt was
made to change the
parameter for the
BufferMode input
variable when re-
executing a motion
control instruction.
(This input variable
cannot be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S Same as
above.
54550000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(D
irection
Selection)
An att
empt was
made to change the
parameter for the
Direction input vari-
able when re-exe-
cuting a motion
control instruction.
(This input variable
cannot be changed
when re-executing
an instruction.)
• An input variable that cannot be
changed for re-execution was
changed.
S Same as
above.
54560000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(Execution
Mode)
An attempt was
made to change the
parameter for the
Periodic input vari-
able when re-exe-
cuting a motion
control instruction.
(This input variable
cannot be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
