Omron NJ Series Troubleshooting Manual

3-61
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-1 Errors by Source
3
3-1-3 Errors in the Motion Control Function Module
54570000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(Axes Group
Specification)
An attempt was
made to change the
parameter for the
AxesGroup input
variable when re-
executing a motion
control instruction.
(This input variable
cannot be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S NJ-series
Motion Con-
trol Instruc-
tions
Reference
Manual (Cat.
No. W508)
54580000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(Jerk Setting)
An attempt was
made to change the
parameter for the
Jerk input variable
when re-executing
a motion control
instruction. (This
input variable can-
not be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S Same as
above.
54590000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(Master Axis)
An attempt was
made to change the
parameter for the
Master input vari-
able when re-exe-
cuting a motion
control instruction.
(This input variable
cannot be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S Same as
above.
545A0000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(MasterOff-
set)
An attempt was
made to change the
parameter for the
MasterOffset input
variable when re-
executing a motion
control instruction.
(This input variable
cannot be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S Same as
above.
545B0000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(MasterScal-
ing)
An attempt was
made to change the
parameter for the
MasterScaling input
variable when re-
executing a motion
control instruction.
(This input variable
cannot be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-e
x
ecution w
as changed.
S S
ame as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
