3 Error Tables
3-62
NJ-series Troubleshooting Manual (W503)
545C0000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(MasterStart-
Distance)
An attempt was
made to change the
parameter for the
MasterStartDis-
tance input variable
when re-executing
a motion control
instruction. (This
input variable can-
not be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S NJ-series
Motion Con-
trol Instruc-
tions
Reference
Manual (Cat.
No. W508)
545D0000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(Continuous)
An attempt was
made to change the
parameter for the
Continuous input
variable when re-
executing a motion
control instruction.
(This input variable
cannot be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S Same as
above.
545E0000 hex Motion Con-
trol Instruc-
tion Re-
execution
Disabled
(MoveMode)
An attempt was
made to change the
parameter for the
MoveMode input
variable when re-
executing a motion
control instruction.
(This input variable
cannot be changed
when re-executing
an instruction.)
• A parameter for an input vari-
able that cannot be changed for
re-execution was changed.
S Same as
above.
545F0000 hex Illegal Auxil-
iary Axis
Specification
The axis specified
for the Auxiliary
input variable to a
motion control
instruction does not
exist.
• An axis does not exist for the
variable specified for the Auxil-
iary input variable to the
instruction.
S Same as
above.
54600000 hex Illegal Axis
Specification
The axis specified
for the Axis input
variable to a motion
control instruction
does not exist.
• An axis does not exist for the
variable specified for the Axis
input variable to the instruction.
S Same as
above.
54610000 hex Illegal Axes
Group Speci-
fication
The axes group
specified for the
Ax
esGroup input
vari
able to a motion
control instruction
does not exist or is
not a used group.
• An axes group does not exist
for the variable specified for the
AxesGroup input variable to the
instruction.
• The axes group specified for
the AxesGroup input variable to
the instruction is not specified
as a used group.
S Same as
above.
54620000 hex Illegal Mas-
ter Axis
Specification
The axis specified
for the Master input
variable to a motion
control instruction
does not exist or is
not a sync master
axis.
• An axis does not exist for the
variable specified for the Master
input variable to the instruction.
• The axis that was specified for
the Master input variable to the
MC_Phasing (Shift Master Axis
Phase) instruction is not the
master axis for syncing.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
