Omron NJ Series Troubleshooting Manual

3 Error Tables
3-66
NJ-series Troubleshooting Manual (W503)
547C0000 hex Circular Inter-
polation
Radius Set-
ting Error
It was not possible
to create a circular
path for the speci-
fied radius when
the radius method
was specified for
the
MC_MoveCircular2
D (Circular 2D
Interpolation)
instruction.
• For the MC_MoveCircular2D
(Circular 2D Interpolation)
instruction, it was not possible
to create a circular path for the
specified radius when the
radius method was specified for
circular interpolation.
S NJ-series
Motion Con-
trol Instruc-
tions
Reference
Manual (Cat.
No. W508)
547D0000 hex Circular Inter-
polation
Radius Over-
flow
For the
MC_MoveCircular2
D (Circular 2D
Interpolation)
instruction, the
radius of the circle
exceeded the maxi-
mum value for the
border point or cen-
ter specification
method.
• For the MC_MoveCircular2D
(Circular 2D Interpolation)
instruction, the radius of the cir-
cle exceeded 40-bit data when
converted to pulses for the bor-
der point or center specifica-
tion method.
S Same as
above.
547E0000 hex Circular Inter-
polation Set-
ting Out of
Range
The parameter
specified for the Cir-
cAxes input variable
to a motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
• The axes that were specified in
CircAxes are not included in the
composition axes in the Axes
Group Settings.
• The same axis was specified
for both axes of CircAxes.
S Same as
above.
547F0000 hex Auxil-
iary/Slave
Axis Num-
bers Not in
Ascending
Order
The values of the
parameters for the
Auxiliary and Slave
input variables to a
motion control
instruction are not
in ascending order.
• The parameters for the Auxil-
iary and Slave input variables to
the instruction are not in
ascending order.
S Same as
above.
54800000 hex Cam Table
Property
Ascending
Data Error at
Update
A phase that was
not in ascending
order was found
during calculating
the number of valid
data. Or, after cal-
culation
s, the
num-
ber of valid data is
0.
• A phase that was not in
ascending order was found
when calculating the number of
valid data.
• After calculations, the number
of valid data is 0.
S Same as
above.
54810000 hex MC_Write
Target Out of
Range
The parameter
specified for the
Target input vari-
able to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54820000 hex Master Travel
Distance
Specification
Out of Range
The parameter
specified for the
MasterDistance
input variable to a
motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
