Omron NJ Series Troubleshooting Manual

3-67
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-1 Errors by Source
3
3-1-3 Errors in the Motion Control Function Module
54830000 hex Master Dis-
tance in
Acceleration
Specification
Out of Range
The parameter
specified for the
MasterDistance-
ACC input variable
to a motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S NJ-series
Motion Con-
trol Instruc-
tions
Reference
Manual (Cat.
No. W508)
54840000 hex Master Dis-
tance in
Deceleration
Specification
Out of Range
The parameter
specified for the
MasterDistan-
ceDEC input vari-
able to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54870000 hex Execution
Mode Selec-
tion Out of
Range
The parameter
specified for the
ExecutionMode
input variable to a
motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54880000 hex Permitted
Following
Error Out of
Range
The parameter
specified for the
PermittedDeviation
input variable to a
motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54890000 hex Border
Point/Center
Posi-
tion/Radius
Specification
Out of Range
The parameter
specified for the
AuxPoint input vari-
able to a motion
control instruction is
out of range.
• The value of AutPoint exceeded
signed 40-bit data when con-
verted to pulses for the border
point or center specification
method.
• For a radius specifications, the
absolute value of AuxPoint[0]
exceeded 40-bit data when
converted to pulses.
S Same as
above.
548A0000 hex End Point
Specification
Out of Range
The parameter
specified for the
EndPoint input vari-
able to a motion
control instruction is
out of range.
•
The instruction input parameter
e
xceeded the r
ange of signed
40-bit data when it is converted
to pulses.
S Same as
above.
548B0000 hex Slave Travel
Distance
Specification
Out of Range
The parameter
specified for the
SlaveDistance input
variable to a motion
control instruction is
out of range.
• The instruction input parameter
exceeded the range of 40-bit
data when it is converted to
pulses.
S Same as
above.
548C0000 hex Phase Shift
Amount Out
of Range
The parameter
specified for the
PhaseShift input
variable to a motion
control instruction is
out of range.
• The absolute value of the
instruction input parameter
exceeded the range of 40-bit
data when it is converted to
pulses.
S Same as
above.
548D0000 hex Feeding Dis-
tance Out of
Range
The parameter
specified for the
FeedDistance input
variable to a motion
control instruction is
out of range.
• The absolute value of the
instruction input parameter
exceeded the range of 40-bit
data when it is converted to
pulses.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
