Omron NJ Series Troubleshooting Manual

3 Error Tables
3-68
NJ-series Troubleshooting Manual (W503)
548E0000 hex Auxiliary and
Slave
Defined as
Same Axis
The same axis was
specified for the
Auxiliary and Slave
input variables to a
motion control
instruction.
• The parameter is the same for
the Auxiliary and Slave input
variables to the instruction.
S NJ-series
Motion Con-
trol Instruc-
tions
Reference
Manual (Cat.
No. W508)
548F0000 hex Relative
Position
Selection Out
of Range
The parameter
specified for the
Relative input vari-
able to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54900000 hex Cam Transi-
tion Specifi-
cation Out of
Range
The parameter
specified for the
CamTransition input
variable to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54910000 hex Synchro-
nized Con-
trol End
Mode Selec-
tion Out of
Range
The parameter
specified for the
OutMode input vari-
able to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54920000 hex Enable Exter-
nal Latch
Instruction
Execution
Disabled
_mcImmediateStop
was specified for
the StopMode input
variable when the
MC_TouchProbe
(Enable External
Latch) instruction
was executed in
Drive Mode, but the
Control Mode was
not CSP Mode.
• _mcImmediateStop was speci-
fied for the StopMode input
variable when the
MC_TouchProbe (Enable Exter-
nal Latch) instruction was exe-
cuted in Drive Mode, but the
Control Mode was not CSP
Mode or the Servo was OFF.
S Same as
above.
54930000 hex Master Axis
Offset Out of
Range
T
he parameter
specified for the
MasterOffset input
variable to a motion
control instruction is
out of range.
• The instruction input parameter
exceeded the range of signed
40-bit data when it is converted
to pulses.
S Same as
above.
54940000 hex Slave Axis
Offset Out of
Range
The parameter
specified for the
SlaveOffset input
variable to a motion
control instruction is
out of range.
• The instruction input parameter
exceeded the range of signed
40-bit data when it is converted
to pulses.
S Same as
above.
54950000 hex Command
Current Posi-
tion Count
Selection Out
of Range
The parameter
specified for the
CmdPosMode input
variable to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54960000 hex Master Axis
Gear Ratio
Numerator
Out of Range
The parameter
specified for the
RatioNumerator-
Master input vari-
able to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
