Omron NJ Series Troubleshooting Manual

3-69
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-1 Errors by Source
3
3-1-3 Errors in the Motion Control Function Module
54970000 hex Master Axis
Gear Ratio
Denominator
Out of Range
The parameter
specified for the
RatioDenominator-
Master input vari-
able to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S NJ-series
Motion Con-
trol Instruc-
tions
Reference
Manual (Cat.
No. W508)
54980000 hex Auxiliary Axis
Gear Ratio
Numerator
Out of Range
The parameter
specified for the
RatioNumera-
torAuxiliary input
variable to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54990000 hex Auxiliary Axis
Gear Ratio
Denominator
Out of Range
The parameter
specified for the
RatioDenomina-
torAuxiliary input
variable to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
549A0000 hex Master Axis
Position Type
Selection Out
of Range
The parameter
specified for the
ReferenceType-
Master input vari-
able to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
549B0000 hex Auxiliary Axis
Position Type
Selection Out
of Range
The parameter
specified for the
ReferenceTypeAux-
iliary input variable
to a motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
549C0000 hex Target Posi-
tion Ring
Counter Out
of Range
Operation is not
possible because
the target position
is out of range for
the ring counter of
the executed
instruction.
• High-speed homing was exe-
cuted when 0 was not included
in the ring counter.
S Same as
above.
549D0000 hex
(Ver. 1.01)
Axes Group
Composition
Axis Setting
Out of Range
The parameter
specified for the
Ax
es input var
iable
to a motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
549E0000 hex
(Ver. 1.04)
Axis Use Set-
ting Out of
Range
The parameter
specified for the
AxisUse input vari-
able to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
57000000 hex
(Ver. 1.03)
Homing
Parameter
Setting Out of
Range
The parameter
specified for the
HomingParameter
input variable to a
motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
