Omron NJ Series Troubleshooting Manual

3-95
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-1 Errors by Source
3
3-1-7 Errors in Slave Terminals
64F10000 hex Unit Over
Range for
Channel 2
The analog input
data for input chan-
nel 2 exceeded the
upper limit of the
input range. Or, the
analog output data
for output channel 2
exceeded the upper
limit of the output
range.
• The analog input data
exceeded the upper limit of the
input range. Or, the analog out-
put data exceeded the upper
limit of the output range.
US NX-series
Analog I/O
Units User’s
Manual
(W522)
64F20000 hex Unit Over
Range for
Channel 3
The analog input
data for input chan-
nel 3 exceeded the
upper limit of the
input range. Or, the
analog output data
for output channel 3
exceeded the upper
limit of the output
range.
• The analog input data
exceeded the upper limit of the
input range. Or, the analog out-
put data exceeded the upper
limit of the output range.
US Same as
above.
64F30000 hex Unit Over
Range for
Channel 4
The analog input
data for input chan-
nel 4 exceeded the
upper limit of the
input range. Or, the
analog output data
for output channel 4
exceeded the upper
limit of the output
range.
• The analog input data
exceeded the upper limit of the
input range. Or, the analog out-
put data exceeded the upper
limit of the output range.
US Same as
above.
64F40000 hex Unit Over
Range for
Channel 5
The analog input
data for input chan-
nel 5 exceeded the
upper limit of the
input range. Or, the
analog output data
for output channel 5
exceeded the upper
limit of the output
range.
• The analog input data
exceeded the upper limit of the
input range. Or, the analog out-
put data exceeded the upper
limit of the output range.
US Same as
above.
64F50000 hex Unit Over
Range for
Channel 6
The analog input
data for input chan-
nel 6 exceeded the
upper limit of the
input range. Or, the
analog output data
for output channel 6
exceeded the upper
limit of the output
range.
• The analog input data
exceeded the upper limit of the
input range. Or, the analog out-
put data exceeded the upper
limit of the output range.
US Same as
above.
64F60000 hex Unit Over
Range for
Channel 7
The analog input
data for input chan-
nel 7 exceeded the
upper limit of the
input range. Or, the
analog output data
for output channel 7
exceeded the upper
limit of the output
range.
• The analog input data
exceeded the upper limit of the
input range. Or, the analog out-
put data exceeded the upper
limit of the output range.
US Same as
a
bove.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
