Omron NJ Series Troubleshooting Manual

3-171
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-2 Events in Order of Event Codes
3
3-2-2 Error Table
54950000 hex Command Current Position Count
Selection Out of Range
Motion Control Instructions W508
54960000 hex Master Axis Gear Ratio Numerator
Out of Range
Motion Control Instructions W508
54970000 hex Master Axis Gear Ratio Denominator
Out of Range
Motion Control Instructions W508
54980000 hex Auxiliary Axis Gear Ratio Numerator
Out of Range
Motion Control Instructions W508
54990000 hex Auxiliary Axis Gear Ratio Denomina-
tor Out of Range
Motion Control Instructions W508
549A0000 hex Master Axis Position Type Selection
Out of Range
Motion Control Instructions W508
549B0000 hex Auxiliary Axis Position Type Selection
Out of Range
Motion Control Instructions W508
549C0000 hex Target Position Ring Counter Out of
Range
Motion Control Instructions W508
549D000 hex* Axes Group Composition Axis Setting
Out of Range
Motion Control Instructions W508
549E0000 hex* Axis Use Setting Out of Range Motion Control Instructions W508
54A00000 hex Results Information, ID Tag Address
Error
CJ-series ID Sensor Units Z317
54A10000 hex Results Information, Write Protection
Error
CJ-series ID Sensor Units Z317
54A20000 hex Results Information, Command Error CJ-series ID Sensor Units Z317
54A80000 hex Command Error CJ-series Serial Communications
Units
W494
54A90000 hex Sequence Abort Completed CJ-series Serial Communications
Units
W494
54AA0000 hex Protocol Macro Error CJ-series Serial Communications
Units
W494
54AE0000 hex Multiple Switches ON Error CJ-series EtherNet/IP Units W495
54AF0000 hex Variable Access Error CJ-series EtherNet/IP Units W495
54E00000 hex Variable Access Error Built-in EtherNet/IP Port on CPU Unit W506
55000000 hex* Division by Zero NX-series Safety Control Unit Z930
55010000 hex* Cast Error NX-series Safety Control Unit Z930
55020000 hex* MUX Error NX-series Safety Control Unit Z930
57000000 hex* Homing Parameter Setting Out of
Range
Motion Control Instructions W508
57020000 hex* Axis Use Change Error Motion Control Instructions W508
57030000 hex* Cannot Change Axis Use Motion Control Instructions W508
571D0000 hex* Too Many Reset Motion Control Error
Instructions
General Motion Control W507
57200000 hex* Motion Control Parameter Setting
Error When Changing Axis Use
Motion Control Instructions W508
57210000 hex* Required Process Data Object Not
Set When Changing Axis Use
Motion Control Instructions W508
57220000 hex* Actual Position Overflow/Underflow Motion Control Instructions W508
57230000 hex* Switch Structure Track Number Set-
ting Out of Range
Motion Control Instructions W508
57240000 hex* Switch Structure First ON Position
Setting Out of Range
Motion Control Instructions W508
Event code Event name Functional classification Reference

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
