Omron NJ Series Troubleshooting Manual

3 Error Tables
3-32
NJ-series Troubleshooting Manual (W503)
5401544A hex Instruction Execu-
tion Error Caused
by Count Mode
Setting
An instruction that cannot
be used when the Count
Mode is set to Rotary Mode
was executed for an axis
that was set to Rotary
Mode.
• An instruction that
cannot be used when
the Count Mode is set
to Rotary Mode was
executed for an axis
that was set to Rotary
Mode.
S NJ-series
Instruc-
tions Ref-
erence
Manual
(Cat. No.
W502)
5401544C hex Parameter Selec-
tion Out of Range
The parameter specified for
the ParameterNumber
input variable to a motion
control instruction is out of
range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401544D hex Stop Method
Selection Out of
Range
The parameter specified for
the StopMode input vari-
able to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401544E hex Latch ID Selection
Out of Range for
Trigger Input Con-
dition
The parameter specified for
the TriggerInput::LatchID
input variable to a motion
control instruction is out of
range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401544F hex Setting Out of
Range for Writing
MC Setting
The parameter specified for
the SettingValue input vari-
able to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
• The parameter specifi-
cation and the data
type of the setting
value do not agree.
S Same as
above.
54015450 hex Trigger Input Con-
dition Mode Selec-
tion Out of Range
The parameter specified for
the TriggerInput:: Mode
input variable to a motion
control instruction is out of
range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015451 hex Drive Trigger Sig-
nal Selection Out
of Range for Trig-
ge
r Input Condition
The par
ameter specified for
the TriggerInput::Input-
Drive input variable to a
motion control instruction is
out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015453 hex Motion Control
Instruction Re-exe-
cution Disabled
(Axis Specification)
An attempt was made to
change the parameter for
the Axis input variable
when re-executing a motion
control instruction. (This
input variable cannot be
changed when re-executing
an instruction.)
• A parameter for an
input variable that can-
not be changed for re-
execution was
changed.
S Same as
above.
54015454 hex Motion Control
Instruction Re-exe-
cution Disabled
(Buffer Mode
Selection)
An attempt was made to
change the parameter for
the BufferMode input vari-
able when re-executing a
motion control instruction.
(This input variable cannot
be changed when re-exe-
cuting an instruction.)
• A parameter for an
input variable that can-
not be changed for re-
execution was
changed.
S Same as
above.
54015455 hex Motion Control
Instruction Re-exe-
cution Disabled
(Direction Selec-
tion)
An attempt was made to
change the parameter for
the Direction input variable
when re-executing a motion
control instruction. (This
input variable cannot be
changed when re-executing
an instruction.)
• An input variable that
cannot be changed for
re-execution was
changed.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Refer-
ence
Maj Prt Min Obs Info
