Appendices
A - 48
NX-series Position Interface Units User’s Manual (W524)
• Set this object to the wait time until the next frame can be sent.
• Set this object to the duration from when the last clock is sent until the high level is confirmed on the
data line.
• Set this object to the wait time from the falling edge of the first clock signal to the rising edge.
Wait time = Clock period × Set value
• If the object is set to 0, the wait time is half of the clock period.
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5002 --- Wait Time for Receive
Enabled
--- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Wait Time for
Receive Enabled
0 0 to 9999 10 μsUINTRWNoY
02 Ch2 Wait Time for
Receive Enabled
*2
*2. This object does not exist on the NX-ECS112.
0 0 to 9999 10 μsUINTRWNoY
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5003 --- Monoflop Time --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Monoflop Time 4 1 to 9999 10 μsUINT RWNoY
02
Ch2 Monoflop Time
*2
*2. This object does not exist on the NX-ECS112.
4 1 to 9999 10 μsUINT RWNoY
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5004 --- Conversion Wait Time --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Conversion Wait
Time
0 0 to 64 --- USINT RW No Y
02 Ch2 Conversion Wait
Time
*2
*2. This object does not exist on the NX-ECS112.
0 0 to 64 --- USINT RW No Y
