Appendices
NX-series Position Interface Units User’s Manual (W524)
A-2 Object Lists
A
A-2-3 SSI Input Units
• Set this object to the valid data length for SSI data.
• If the sum of the valid data length and the leading bits is greater than 32, SSI communications are
disabled and an SSI Data Setting Error event occurs.
• Set this object to the start bit position for single-turn data.
• If the sum of the values set for the Single-turn Data Start Bit and the Single-turn Data Length objects
is greater than the Valid Data Length object, SSI communications are disabled and an SSI Data Set-
ting Error event occurs.
• Set this object to the data length for single-turn data.
• If the sum of the values set for the Multi-turn Data Length, Single-turn Data Length, and Status Data
Length objects is greater than 32, SSI communications are disabled and an SSI Data Setting Error
event occurs.
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5005 --- Valid Data Length --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Valid Data Length 25 1 to 32 Bit USINT RW No Y
02
Ch2 Valid Data Length
*2
*2. This object does not exist on the NX-ECS112.
25 1 to 32 Bit USINT RW No Y
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5006 --- Single-turn Data Start Bit --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Single-turn Data Start
Bit
12 0 to 31 --- USINT RW No Y
02 Ch2 Single-turn Data Start
Bit
*2
*2. This object does not exist on the NX-ECS112.
12 0 to 31 --- USINT RW No Y
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5007 --- Single-turn Data Length --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Single-turn Data
Length
13 0 to 32 Bit USINT RW No Y
02 Ch2 Single-turn Data
Length
*2
*2. This object does not exist on the NX-ECS112.
13 0 to 32 Bit USINT RW No Y
