A - 51
Appendices
NX-series Position Interface Units User’s Manual (W524)
A-2 Object Lists
A
A-2-3 SSI Input Units
• Set this object to the data length for status data.
• If the sum of the multi-turn data length, single-turn data length, and status data length is greater than
32, SSI communications are disabled and an SSI Data Setting Error event occurs.
• Set this object to the leading bits for SSI data.
• If the sum of the valid data length and the leading bits is greater than 32, SSI communications are
disabled and an SSI Data Setting Error event occurs.
• The following table shows the settings for the Parity Check object.
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
500B --- Status Data Length --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Status Data Length 0 0 to 32 Bit USINT RW No Y
02 Ch2 Status Data Length
*2
*2. This object does not exist on the NX-ECS112.
0 0 to 32 Bit USINT RW No Y
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
500C --- Leading Bits --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Leading Bits 0 0 to 31 Bit USINT RW No Y
02
Ch2 Leading Bits
*2
*2. This object does not exist on the NX-ECS112.
0 0 to 31 Bit USINT RW No Y
Index
(hex)
Subin-
dex
(hex)
Object name Default
Data
range
Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
500D --- Parity Check --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Parity Check 0 0 to 2 --- USINT RW No Y
02
Ch2 Parity Check
*2
*2. This object does not exist on the NX-ECS112.
0 0 to 2 --- USINT RW No Y
Set value Description
0 No check
1 Even parity check
2 Odd parity check
