Omron NX-EC0122 User Manual

A - 61
Appendices
NX-series Position Interface Units User’s Manual (W524)
A-2 Object Lists
A
A-2-4 Pulse Output Units
• The following table shows the settings for the External Input 1 Logic Selection object.
• The following table shows the settings for the External Output 0 Function Selection object.
• The following table shows the settings for the External Output 0 Logic Selection object.
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5015 --- External Input 1 Logic
Selection
--- --- --- --- --- --- ---
00 Number of Entries 1 1 --- USINT RO No ---
01 Ch1 External Input 1
Logic Selection
0 0 or 1 --- USINT RW No Y
Set value Description
0 N.O. (Normally open)
1 N.C. (Normally close)
Index
(hex)
Subin-
dex
(hex)
Object name Default
Data
range
Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5018 --- External Output 0 Func-
tion Selection
--- --- --- --- --- --- ---
00 Number of Entries 1 1 --- USINT RO No ---
01 Ch1 External Output 0
Function Selection
0 0 or 1 --- USINT RW No Y
Set value Description
0 General output
1 Error counter reset output
Index
(hex)
Subin-
dex
(hex)
Object name Default
Data
range
Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5019 --- External Output 0 Logic
Selection
--- --- --- --- --- --- ---
00 Number of Entries 1 1 --- USINT RO No ---
01 Ch1 External Output 0
Logic Selection
0 0 or 1 --- USINT RW No Y
Set value Description
0 N.O. (Normally open)
1 N.C. (Normally close)
