4-6
4-1 Installation Conditions
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
4
System Design
Decelerator Installation Conditions
Using Another Company's Decelerator (Reference)
If the system configuration requires another company's decelerator to be used in combination
with an OMNUC G5-Series motor, select the decelerator so that the load on the motor shaft
(i.e., both the radial and thrust loads) is within the allowable range. (Refer to
"Characteristics"(P.3-2) for details on the allowable loads for the motors.)
Also, select the decelerator so that the allowable input rotation speed and allowable input
torque of the decelerator are not exceeded.
To Next Page
