1-16
1-5 Applicable Standards
1
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
Features and System Configuration
The Servo Drives and Servomotors comply with UL 508C (file No. E179149) as long as the
following installation conditions 1 and 2 are met.
(1) Use the Servo Drive in a pollution degree 1 or 2 environment as defined in IEC 60664-
1 (example: installation in an IP54 control panel).
(2) Be sure to connect a circuit breaker or fuse, which is a UL-listed product with LISTED
and mark, between the power supply and noise filter.
Refer to the following table for the rated current of the circuit breaker or fuse.
Use copper wiring with a temperature rating of 75°C or higher.
*1: 100 A when used in combination with the R88M-K11K015T-@. 125A when used in combination with
the R88M-K15K015T-@.
*2: 50 A when used in combination with the R88M-K11K015C-@. 60 A when used in combination with the
R88M-K15K015C-@.
Korean Radio Regulations (KC)
The G5-series Servo Drives comply with the Korean Radio Regulations (KC).
The G5-series Servomotors and Linear Motors are exempt from the Korean Radio
Regulations (KC).
Drive model Circuit breaker (rated current) (A)
R88D-KT01L 10
R88D-KT02L 10
R88D-KT04L 10
R88D-KT01H 10
R88D-KT02H 10
R88D-KT04H 10
R88D-KT08H 15
R88D-KT10H 15
R88D-KT15H 20
R88D-KT20H 30
R88D-KT30H 50
R88D-KT50H 50
R88D-KT75H 60
R88D-KT150H
100/125 *
1
R88D-KT06F 15
R88D-KT10F 15
R88D-KT15F 15
R88D-KT20F 20
R88D-KT30F 30
R88D-KT50F 30
R88D-KT75F 30
R88D-KT150F
50/60 *
2
