2-1 Servo System Configuration
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
AC Servo Drive
Peripheral Devices
External
Regeneration
Resistors
R88A-RR
External encoder
AC Servomotors
• OMNUC G5 Series Servo Drive
R88D-KT
• OMNUC G5-series Servomotor
R88M-K
Motor power signals
Feedback Signals
Power Cables
•
Without Brake
R88A-CA@@@@@SR-E
•
With Brake
R88A-CA@@@@@BR-E
• Flexible Cables
Encoder Cables
Brake Cables (50 to 750 W max.)
• Flexible Cables
R88A-CAKA@@@BR-E
Absolute Encoder Battery Cable
* Not required if a battery is connected
to the control connector (CN1).
(A battery is included with
model numbers ending in “BS”).
R88A-CRGD0R3C (-BS)
100 VAC
200 VAC
400 VAC
3,000 r/min
2,000 r/min
1,500 r/min
1,000 r/min
USB
communications
• 750 W or less:
R88A-CRKA@@@CR-E
• 1 kW or more:
R88A-CRKC@@@NR-E
●
Flexible Cables
