4-3 Wiring Conforming to EMC Directives
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
4
System Design
Unit Details
*1. A specified combination of Servo Drive and Servomotor must be used.
Cable Details
Symbol Name Manufacturer Model Comment
SG Surge absorber
Okaya Electric
Industries Co., Ltd.
R·A·V-801BXZ-4
NF Noise filter Schaffner EMC Inc.
FN258L-16-07 3-phase 400 VAC (16 A)
FN258L-30-07 3
-phase 400 VAC (30 A)
FN258-42-07 3
-phase 400 VAC (42 A)
SD Servo Drive OMRON − *1
SM Servomotor OMRON − *1
FC1 Clamp core TDK ZCAT3035-1330 −
FC2 Clamp core Konno Industry
RJ8035
−
RJ8095
FC3 Clamp core
MICROMETALS T400-61D For R88D-KT75F/-KT150F
TDK ZCAT3035-1330 For other models
− Controller −− −
Symbol
Supplies from Connects to Cable name
Length
Comment
Shielded
Ferrite
(1) AC power supply Noise filter
Power supply
line
2 m − No No
(2) Noise filter Servo Drive
Power supply
line
2 m − No Optional
(3) Servo Drive Servomotor Power cable 20 m − No Optional
(4) Servo Drive Servomotor
Encoder
cable
20 m − Yes Optional
(5) Switch box Servo Drive I/O cable 2 m − No Optional
(6) Frame ground Noise filter FG line 1.5 m − No No
(7) Frame ground Servo Drive FG line 1.5 m − No No
(8) AC power supply Controller
Power supply
line
1.5 m − No No
