2-3 Standard Model Tables

OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL

Standard Models and External Dimensions

Servo Relay Unit Cables for Position Control Units

Specifications Model

Position Control Unit

cables

For CQM1H-PLB21 (XW2B-20J6-3B) 0.5 m XW2Z-050J-A3

1 m XW2Z-100J-A3

For CS1W-NC113, C200HW-NC113 (XW2B-

20J6-1B)

0.5 m XW2Z-050J-A6

1 m XW2Z-100J-A6

For CS1W-NC213/-NC413, C200HW-NC213/-

NC413 (XW2B-20J6-2B)

0.5 m XW2Z-050J-A7

1 m XW2Z-100J-A7

For CS1W-NC133 (XW2B-20J6-1B) 0.5 m XW2Z-050J-A10

1 m XW2Z-100J-A10

For CS1W-NC233/-NC433 (XW2B-20J6-2B) 0.5 m XW2Z-050J-A11

1 m XW2Z-100J-A11

For CJ1W-NC113 (XW2B-20J6-1B) 0.5 m XW2Z-050J-A14

1 m XW2Z-100J-A14

For CJ1W-NC213/-NC413 (XW2B-20J6-2B) 0.5 m XW2Z-050J-A15

1 m XW2Z-100J-A15

For CJ1W-NC133 (XW2B-20J6-1B) 0.5 m XW2Z-050J-A18

1 m XW2Z-100J-A18

For CJ1W-NC233/-NC433 (XW2B-20J6-2B) 0.5 m XW2Z-050J-A19

1 m XW2Z-100J-A19

For CJ1M-CPU21/-CPU22/-CPU23 (XW2B-

20J6-8A/XW2B-40J6-9A)

0.5 m XW2Z-050J-A33

1 m XW2Z-100J-A33
