2-41
H 1,000-r/min Servomotors without a Brake
D 200 V AC: 300 W/600 W/900 W/1.2 kW/2.0 kW/3.0 kW
R88M-W30010H(-S2)/-W60010H(-S2)/-W90010H(-S2)/-W1K210H(-S2)/
-W2K010H(-S2)/-W3K010H(-S2) [Incremental]
R88M-W30010T(-S2)/-W60010T(-S2)/-W90010T(-S2)/-W1K210T(-S2)/
-W2K010T(-S2)/-W3K010T(-S2) [Absolute]
Four, Z dia.
D1 dia.
D2 dia.
D3 dia.
S dia.
Dimensions of output section
of 300-W to 900-W Servomotors
Dimensions of shaft end
with key (-S2)
M (Effective depth: )
30 dia.
Model
Dimensions (mm)
Model
LL LR KB1 KB2 KL1 KL2 C D1 D2 D3 F G Z S QK b h t1 M

R88M-W30010j-j
138
58
65 117
109 88 130 145 110h7 165 6 12 9 19h6 25 5 5 3 M5 12
R88M-W60010j-j
161
58
88 140
109
88
130
145
110h7
165
6
12
9
19h6
25
5
5
3
M5
12
R88M-W90010j-j
185 112 164 22h6 6 6 3.5
R88M-W1K210j-j
166
79
89 144
140 88 180 200
114.3
0
0 025
230 3.2 18 13.5
35
0.01
0
60 10 8 5 M12 25
R88M-W2K010j-j
192
79
115 170
140
88
180
200
114
.
3
0
–0.025
230
3.2
18
13.5
35
0
.
01
0
60
10
8
5
M12
25
R88M-W3K010j-j
226 149 204
Note The external dimensions are the same for IP67 (waterproof) models (-Oj).
Standard Models and Specifications
Chapter 2
